Tank gauging
Tank Side Monitor NRF590

Field gateway for tank sensor operation and monitoring and integration into inventory control system

  • Tank Side Monitor NRF590 ©Endress+Hauser
  • Tank Side Monitor NRF590 ©Endress+Hauser
  • Tank Side Monitor NRF590 application ©Endress+Hauser
  • Tank Side Monitor NRF590 application ©Endress+Hauser

The Tank Side Monitor NRF590 is a sensor integration and monitoring unit for bulk storage tank gauging applications. It can be used with Micropilot radar or Proservo level gauges and can be combined with other HART compatible devices to communicate tank sensor data to a control host. Various selectable alarms and outputs.

Benefits

  • Intrinsically safe power supply and communication for Micropilot and Levelflex radar level devices

  • Connects up to 6 HART devices via intrinsically safe 2 wire, for example Prothermo, for average temperature measurement and Cerabar/Deltabar for HTMS density applications. RTD input is also available

  • Backlit graphical LCD display; operation via 3 optical keys (touch control)

  • User-friendly operating menu (multi-lingual)

  • Interfaces to tank inventory system Tankvision

  • Provides communication to PLC, DCS and SCADA systems

  • Approved for use in explosion-hazardous areas

Field of application

For intrinsically safe (i.s.) power supply of the connected devices. Parameterization of the connected devices and display of the measured values. Tank calculations for accurate correction of the tank distortions. Weights & Measure-approved for use in custody transfer applications.

  • Output: Modbus EIA485 (RS485), Sakura V1, WM550, L&J, Mark Space, Enraf BPM, GPE

  • Temperature: -40 to 60°C (-40 to 140°F)

  • International explosion protection certificates

Features and specifications

Documents / Manuals / Software

Accessories / Spare parts

Predecessor / Successor

Predecessor: NRF561
